S54 Rodbearing Kit - ACL HX [EARLY]
- Track-Tested Performance Solutions
- In stock, ready to ship
This Kit Includes
| Qty | Part | SKU | Brand | Price |
|---|---|---|---|---|
| 1 | Engine Connecting Rod Bearing Set | ACL-6B1569HXSTD |  |
$164.99 |
| 4 | Power Brake Booster Nut | OES-07119905374 |  |
$7.32 |
| 1 | Engine Oil Pan Cover | BMW-11137832020 |  |
$107.99 |
| 1 | Engine Oil Pan Cover Gasket | BMW-11137832023 | |
$76.50 |
| 1 | Engine Oil Pump Pickup Tube O-Ring | BMW-11411401769 | |
$14.98 |
| 1 | Engine Oil Dipstick Tube O-Ring | BMW-11431707164 | |
$10.79 |
| 12 | Suspension Subframe Reinforcement Bracket Bolt | BMW-31106772199 | |
$65.88 |
| 1 | Steering Shaft Bolt | BMW-32306778609 | |
$3.39 |
| 1 | Engine Oil Pan Gasket | CTO-423978P |  |
$21.61 |
| 1 | Engine Oil Level Sensor Seal | ELR-301540 |  |
$5.12 |
| 1 | Engine Oil Filter Kit | MAH-OX187D |  |
$12.71 |
Product Information
The S54 engine is known for many things. One of its downfalls was the early production E46 M3 rod bearing failures due to mis-manufactured bearings by BMW's supplier. BMW put together service kit 11410395192 which included all parts required to replace worn or defective rod bearings. This kit is no longer available from BMW despite the individual pieces being available.
Models affected:
E46 M3 Convertible:
Chassis Range - EX20040-EX24999
Chassis Range - PK00000-PK03913
E46 M3 Coupe:
Chassis Range - JR10051-JR23641
This kit is intended for early production S54 engines only. The connecting rod bolts are M11x1.25mm bi-hexagonal (12 point) bolts and are intended to be reused. It is required to install the bolts into the same connecting rod location they were removed from. Example, an exhaust side bolt must go back to the exhaust side hole on the connecting rod. Before removal mark the bolt location. The M11x1.25mm connecting rod bolts follow a specific tightening sequence which must be followed:
1) Jointing torque - 5 Nm (~4 ft lbs)
2) Setting torque - 30 Nm (~15 ft lbs)
3) Angle of rotation - 70°
Please note:Â Also inspect the front of your S54's oil pump housing. Some vehicles have had the oil pump chain come into contact with the housing and start removing material as a result. If this has occurred it would also be a good idea to replace the oil pump and oil pump chain/tensioner.
